Features of capability and structure:
1. Modularization designing, multi-function;
2. The key components of the truck is import from world famous factories, such as water pump, high pressure nozzle and hydraulic components;
3. Low pressure watering, high efficiency and saving energy;
4. High pressure watering, high efficiency and saving water;
5. It has the function of sucking up water;
6. Water inlet cover is controlled by gas cylinder, it is convenient to open and close the cover;
7. The tank is made of stainless steel or adopts metal antisepsis;
8. It has stirrer in the tank, mixing snow melting agent or pesticide and water;
9. It can be equipped with snow plough and lifting platform;
10. It can be equipped with sewer dredging equipment.
|
Technical parameters: |
|
|
Vehicle Model |
SMJ5250GQXDC3 |
|
Chassis Model |
DFL1250A8/东风天龙 |
|
Dimension (L*W*H) (mm) |
10720,9790*2495*3030 |
|
Max. speed (km/h) |
90 |
|
Engine Model |
ISDe230 30 |
|
Engine power |
169/2500 |
|
Auxiliary engine model |
4jbi |
|
Auxiliary engine power (kw r/min) |
57/3600 |
|
Cab configure |
Cool and warm air-conditioner |
|
Cleaning speed (km/h) |
0-20 |
|
Cleaning width (m) |
2.5-3.5 |
|
Cleaning angle (°) |
30°to the left and to the right |
|
Max. water pressure (MPa) |
10(6) |
|
Cleaning flow capacity (L/min) |
150(90) |
|
Watering spray width (m) |
≥16 |
|
Watering spray speed (km/h) |
0-20 |
|
Water flow capacity (L/min) |
500-800 |
|
Spraying gun gunshot (m) |
38/ |
|
Water tank volume (L) |
16000 |
|
Max. Total weight (kg) |
25000 |
